| ■ Camera Enclosure ★ ★ ★ ★ |
|
 |
 |
|
|
|
 |
- Fire Retardant ABS Housing.
- 9” Tinted Acrylic Dome Cover.
- Optional heater and fan to maintain working temperature.
- Quick On/Off dome cover for installation & maintenance.
- Panel Mounting Hole: 255 mm
- Meet IP33 Protection level.
- Certification：IP33
|
 |
|
|
|
|
|
|
 |
- 6” Aluminum dome enclosure, suitable for indoor installation.
- 6” Tinted acrylic dome cover.
- Meet IP33 protection level.
- Optional heater and fan to maintain working temperature.
- Quick On / Off dome cover for installation & maintenance.
- A stainless steel retaining cable.
- Panel mounting hole: 225 mm.
- Fluorocarbon baking varnish: endurable environment, resistible acid & base, five years warrant. ( Option )
- Certification：IP33、Pb
|
|
|
|
|
|
|
|
|
|
|
|
|
 |
- 6” Aluminum Dome Enclosure, Suitable for outdoor and indoor installation.
- Double-Decked design strengthens the heat insulation.
- Build-in fan & heater make sure the mechanism works in a certain temperature. ( Option )
- A stainless steel retaining cable.
- Fluorocarbon Baking Varnish: endurable environment, resistible acid & base, five years warrant. ( Option )
- Internal support for camera or adjustment for speed dome and network camera.
- Transparent or Smoke cover. ( Selectable )
- Certification：IP66、Pb、FCC、CE
|
|
|
|
|
|
|
|
|
 |
- 7”Aluminum Dome Enclosure, suitable for outdoor and indoor installation.
- Double-decked design strengthens the heat insulation.
- Build-in Fan & Heat make sure the mechanism works in a certain temperature (Option).
- A stainless steel retaining cable.
- Fluorocarbon Baking Varnish: endurable environment, resistible acid & base, five years warrant (Option).
- Transparent or smoke cover. ( Selectable )
- Certification：IP66、Pb、CE、FCC
|
|
|
|
|
|
|
|
|
|
|
- 7”Aluminum dome enclosure, suitable for outdoor and indoor installation.
- Double-decked design strengthens the heat insulation.
- Build-in fan & heat make sure the mechanism works in a certain temperature (Option).
- A stainless steel retaining cable.
- Fluorocarbon Baking Varnish: endurable environment, resistible acid & base, five years warrant.
- Nitrogen pressurize-able dome enclosure IP 68.
- Vandal proof dome.
- Transparent or smoke cover. ( Selectable )
- Certification：IP68、Pb、CE、FCC.
|
|
|
|
|
|
|
|
|
 |
- 9" Aluminum Dome Enclosure, suitable for Outdoor and Indoor installation.
- Double-decked design strengthens the heat insulation.
- Inner Side – ABS / Outer Side – Aluminum / Cover – Acrylic.
- Built-in Fan & Heater to make sure the mechanism work in a precise temperature. (Optional)
- Equipped with a stainless steel retaining cable.
- FEVE Coating：Endurable environment, resistible acid & base, five years warranty. (Optional)
- Internal support for camera or adjustment for speed dome and network camera.
- Wall Mount Bracket or Pendant Mount Bracket. (Selectable)
- Certification：IP66、Pb.
|
| |
|
|
|
|
|
|
 |
- Accept all standard CCTV cameras.
- Maximize flexibility during installation.
- LEXAN polycarbonate window with ABS cover.
- Fixed part with rugged heavy gauge steel construction.
- Maximum Camera/Lens dimension：150 mm（L）
|
|
|
|
|
|
 |
- Outdoor back open camera housing.
- Aluminum camera enclosure.
- Appearance size：147 (W) x 140 (H) x 470(L) mm.
- Suitable camera size：105 (W) x 100 (H) x 320(L) mm.
- Control temperature：Heater (ON / 15℃，OFF 25℃) Control temperature：Blower (ON / 35℃，OFF / 25℃)
- Input voltage：12VDC / 24VAC / 110VAC / 220VAC.
- Packing：10 pcs in one.
- Certification：IP66
|
|
|
|
|
|
|
 |
- Outdoor back open camera housing.
- Aluminum camera enclosure.
- Appearance size：157（W）x 130（H）x 460(L) mm.
- Suitable camera size：108(W）x75(H）x300(L）mm.
- Control temperature：Heater (ON / 15℃，OFF 25℃)
Control temperature：Blower (ON / 35℃，OFF / 25℃)
- Input voltage：12VDC / 24VAC / 110VAC / 220VAC.
- Packing：6 pcs in one.
- Certification：IP66
|
|
|
|
 |
|
| |
Model |
| AXIS |
212 |
| JVC |
VN-C215V/C215VP、VN-V225VP、VN-X235VP |
| PANASONIC |
HCM-581 、 HCM-584 、 WV-NS202A、WV-NW502S、WV-NW484S、WV-NF302 、 WV-NF284 、 WV-CW500S/504S 、 WV-CW480/484、WV-CW240/244 |
| SAMSUNG |
SID-450P、SID-460P、SID-500P、SID-560P/562P、SVD-4300P、SVD-4600P、SPD-1000P |
| ELMO |
PTC-1000 Series、PTC-201C IP Series、PTC-400C Series |
| VIVOTEK |
PT3112、PT3122、PZ6112、PZ6122、PT7135、PZ7111、PZ7112、PZ7121、PZ7151 、PT3117、PT3127、PZ6114、PZ6124、PT7137、PZ7132、PZ7152 |
| CANON |
VB-C300/C300B、SNC-P5、SNC-DF40N |
| D-LINK |
DCS-5300 、 DCS-5300G 、 DCS-5610 、 DCS-5610G、DCS-6620、DCS-6620G 、DCS-5220G、DCS-5300G |
| ACTI |
ACM-8201、ACM-8211、ACM-8511 |
| PLUSTEK |
P100、P1000A、P1100AF |
| SANYO |
VCC-VH400 |
|
|
 |
|
| |
Model |
| AXIS |
213、214、215、231D+、232D+、233D、P5334 |
| JVC |
VN-C625、VN-C685、VN-C686B、VN-V686WPB |
| PANASONIC |
WV-CS950 、 WV-CS954 、 WV-NS950 、 WV-NS954 、 WV-CS570、WV-CS574 |
| SAMSUNG |
SPD-3750P/3750TP、SPD-3350P、SPD-3300P、SPD-3100P、SPD-2310P/2300P |
| SANYO |
VCC-9300P、VCC-9400P、VCC-9600、VCC-9800 |
| SONY |
SNC-RZ25、SNC-RZ30 SNC-RZ50、SNC-DF70N |
| CANON |
VB-C300-C300B、VB-C50I/C50IR、VC-C50I/C50IR |
|
|
 |
|
| |
Model |
| SONY |
SNC-RX530、SNC-RX550、SNC-RX570 |
|
|
